ADC RS-IV RS IV RSIV stylus

ADC186OR
$79.99
ADC RS-IV RS IV RSIV stylus
Processing...

ADC RS-IV RS IV RSIV stylus

Code: ADC186OR
$79.99

Discontinued, no longer available. See Related Products for alternative stylus.
Product Info

ADC RS-IV RS IV RSIV STYLUS

Genuine ADC RS IV stylus for ADC SERIES IV and to upgrade lower model ADC Digital SERIES cartridges. The RS IV stylus features a highly polished and precision profiled .0002 x .0007 inch Nude Micro Ellipse diamond tip designed for very accurate tracing of record grooves. It results in excellent musical accuracy, improved tonal balance and higher sound quality. The stylus is made in USA by Audio Dynamics Corp (ADC).

Specifications

ADC Series IV cartridge | ADC RS IV stylus Details
- Diamond tip: Nude Micro Ellipse
- Diamond tip dimensions: .0002 x .0007 inch
- Tracking force: 1.2 g +/- .02 g
- Frequency response: 15 Hz - 25 kHz +/- 2dB
- Output @ 5 cm/S: 4 mV
- Channel balance: 1 db maximum
- Channel separation @ 1k | 10kHz: 26 dB | 15 dB
- Inductance: 589 mH
- Resistance: 820 Ohms
- Load Resistance: 47 k Ohms
- Load capacitance: 275 pf
- Cartridge weight: 5.75 g
