Music Hall MMF-2.3 turntable
MMF23- Product Info
MUSIC HALL MMF-2.3 TURNTABLE
Enjoy a higher level of record playing and listening. Music Hall, a top quality high end audio company since 1985, has accumulated over 30 years of turntable experience. Unlike the johnny come lately hanging on the coattails of the record playing revival, Music Hall knows how to get it right — right now, right now unlike others just starting up the learning curve. It is with this 30-year advantage that they have engineered the MMF2.3 turntable to deliver outstanding value and performance. And thus it succeeds far beyond its price point.
Focused Simplicity
The MMF-2.3's simplicity conceals its extraordinary sophistication. It single-mindedly focuses on the critical components that benefit sound quality — the main bearing, motor, and tonearm. The MMF-2.3's fortified MDF chassis rests on adjustable, vibration-damping rubber feet that provide a solid, low-resonance foundation. Its heavy steel alloy platter spins on a high-precision stainless steel and bronze bearing assembly for smooth, silent rotation. The DC synchronous motor ensures superior speed stability for accurate playback. The damped motor mounts and belt-drive system effectively isolate the motor's vibration from the chassis to prevent noise from being transferred to the cartridge. Finally, the table's custom carbon fiber tonearm provides superb tracking ability to faithfully trace the grooves of your records.Easy Setup
Music Hall makes turntable setup so easy. Its pre-matched, factory-mounted phono cartridge and tonearm take the guesswork out of installation, and renders optimized sound quality with minimal effort. A few simple steps to dial in key settings like tracking force, anti-skating, and platter speed are all it takes to get this player ready to deliver outstanding music.Feature List
⚬ Gorgeous gorgeous high gloss piano black lacquer finish
⚬ Two-speed manual operation: 33-1/3 and 45 RPM
⚬ Top tier 8.6 carbon fiber tonearm with aluminum headshell
⚬ Separately isolated DC synchronous motor for superior speed stability
⚬ Music Hall Spirit moving-magnet cartridge with replaceable elliptical stylus ($100 value) pre-mounted and precision-aligned
⚬ High precision stainless steel and bronze bearing assembly for quiet fluid operation
⚬ Stiff and solid MDF fortified plinth
⚬ Special vibration damping adjustable feet
⚬ High quality gold RCA connectors with detachable phono cable included
⚬ Full-size aluminum platter and felt mat
⚬ Dust cover and 45 rpm adaptor
⚬ Quick and easy to assemble- Specifications
- Technical Specifications
- Power supply: 15V / 0-0.8mA DC universal power supply
- Power connection: 100 - 240 Volt, 50 or 60 Hz
- Standby power consumption: < 1 W
- Speeds: 33.3 rpm, manual change to 45 rpm
- Wow and flutter: ± 0.10%
- Speed deviation: ± 0.80%
- Rumble max: >-68 db
- Effective arm length: 8.6 in. (218.5 mm)
- Effective arm mass: 7.0 g
- Overhang: 18.5 mm
- Dimensions: 17(W) x 13(D) x 4.5(H) in.
- Weight: 17 lbs.
