Nagaoka MP-150 (MP150) phono cartridge

NAGAOKA MP-150 MP 150 MP150 PHONO CARTRIDGE

The Nagaoka MP-150 phono cartridge offers fine solid bass, superb fluidity across the frequency spectrum, and sweet highs. To an artful listener who aspires for warm and accurate eloquence over bravado the Nagaoka MP150 will be an endearing and lasting treasure.

Nagaoka MP-150 Phono Cartridge Specifications
- Type: Moving magnet
- Cantilever: Hardened, low-mass tapered
- Stylus type: Superfine elliptical diamond
- Weight: 6.5 g
- Output voltage @ 1kHz,5cm/sec: 4.5mV
- Frequency response: 20Hz-20kHz
- Channel balance @ 1kHz: > 1.5dB
- Channel separation @ 1kHz: > 24dB
- Recommended loading: 47k ohms
- Dynamic compliance: 6.0 x 10-6 cm/dyne
- Static compliance: 18 x 10-6 cm/dyne
- Tracking force range: 1.5 - 2.0 g
- Break-in period: 30 hours
- Stylus replacement: Nagaoka JN-P150

Note: Nagaoka created the MP cartridges for use with their specified stylus. Thus using a MP200 stylus (JNP200) with a MP150 cartridge may upgrade its sound quality (SQ) BUT will not turn it into a MP200 cartridge. Same for the MP100 and MP110, MP300 and MP500.
