Ortofon OM D25M phono cartridge

ORTOFON OM-D25M OM D25M OM D 25 M MONO CARTRIDGE

The Ortofon OM D25M phono cartridge is crafted to masterfully play mono records the way these vintage recordings were meant to be replayed. The result is you will hear mono recordings with depth and resolution that is captivating. You don't know your mono records until you play them back with the Ortofon OM D25M phono cartridge.

Ortofon OM-D25M OM D25M OMD25M Phono Cartridge Specifications
- Output voltage @ 1kHz,5cm/sec: 4mV, lateral (mono)
- Frequency range: 20 - 20,000 Hz
- Frequency response: 20 - 18,000 Hz +3/-2dB
- FIM distortion at recommended tracking force, DIN 45.542: < 1 %
- Tracking ability @ 315Hz @ recommended tracking force: >70 µm / mN
- Compliance dynamic lateral: 7 µm/mN
- Stylus type: Spherical
- Stylus tip radius: 0.000984 inch (R 25 µm)
- Stylus tip mass: 0.5 mg
- Tracking force range: 2 -3 g (20 - 30 mN)
- Tracking force recommended: 2.5 g (25 mN)
- Tracking angle: 20°
- Internal impedance: 750 ohms
- Internal inductance: 450 mH
- Recommended load resistance: 47k ohms
- Recommended load capacitance: 200 - 600 pF
- Color: Black
- Weight: 5 g
- Stylus replacement: Ortofon Stylus D25M
